Bin Packing

A Rust-first cut list and bin packing optimization library for one-dimensional cutting stock (linear bar / pipe stock), two-dimensional rectangular sheet stock, and three-dimensional box-into-bin packing problems. The crate is #![forbid(unsafe_code)], integer-math oriented, and serde-friendly so problems and solutions travel cleanly across process boundaries and language bindings.

Core crate: crates/bin-packing — published to crates.io as bin-packing.
Node.js bindings: bindings/node — published to npm as @0xdoublesharp/bin-packing, powered by napi-rs.
WebAssembly bindings: bindings/wasm — published to npm as @0xdoublesharp/bin-packing-wasm, powered by wasm-bindgen. Runs in browsers, Node.js, Deno, Bun, and Cloudflare Workers.
Fuzz targets: fuzz/ — libFuzzer harnesses for the 1D, 2D, and 3D entry points.

Features

1D cutting stock

Multi-stock support. Mix any number of stock dimensions with independent length, kerf, trim, cost, and optional inventory available caps.
Kerf and trim modeling. Each layout deducts trim from usable length and charges kerf between adjacent cuts, so results match physical cut lists.
Inventory-aware procurement. When stock has available caps, the solver returns both the capped solution and a relaxed-inventory estimate so you can see per-stock used_quantity, required_quantity, and additional_quantity_needed.
Multi-objective ranking. Solutions are compared lexicographically by (unplaced, stock_count, total_waste, total_cost, !exact) so better heuristic candidates win automatically in Auto mode.
Lower bounds. The column-generation backend reports an LP lower bound and marks the solution exact = true when it matches the incumbent.
Structured errors. Public boundary validation fails fast with typed BinPackingError variants instead of panics.

3D box packing

Multi-bin support. Mix any number of bin types with independent width, height, depth, cost, and optional quantity caps.
Per-item rotation control. Each demand has an allowed_rotations bitmask over the six axis-permutation orientations of (w, h, d). RotationMask3D::ALL allows all six; RotationMask3D::UPRIGHT permits only the two orientations that keep the declared y axis vertical.
29-algorithm catalog. Includes Extreme Points (6 scoring variants), Guillotine 3D beam search (7 variants), horizontal layer-building (5 inner-2D backends), Bischoff & Marriott vertical wall-building, column / stack building, Deepest-Bottom-Left and DBLF, volume-sorted FFD/BFD, Multi-start, GRASP, and Local Search meta-strategies, plus a restricted Martello-Pisinger-Vigo branch-and-bound exact backend.
Same ranking contract. Solutions are compared lexicographically by (unplaced, bin_count, total_waste_volume, total_cost, !exact), so Auto mode always returns the best candidate.
Dimension safety. Per-axis dimensions are capped at 1 << 15 (MAX_DIMENSION_3D) so that w × h × d never overflows u64.

2D rectangular packing

Multi-sheet support. Mix any number of sheet types with independent width, height, cost, and optional quantity caps.
Per-item rotation control. Each demand has its own can_rotate flag; the solver enumerates the legal orientations per item.
Guillotine mode. guillotine_required = true restricts the Auto strategy to guillotine-compatible constructions and sets TwoDSolution.guillotine on the result.
Kerf-aware packing. Each sheet type accepts an optional kerf gap (in the same units as the sheet dimensions). The solver enforces the gap between every pair of adjacent placements (factory edges are free; only internal cuts consume kerf). The solution reports kerf_area per layout and total_kerf_area across all sheets.
Edge kerf relief. Set Sheet2D.edge_kerf_relief = true to allow a trailing placement to extend up to one kerf past the sheet boundary, modeling a blade that exits the stock. Parts must still fit within the declared sheet dimensions.
Multistart search. A randomized MaxRects meta-strategy (multi_start) permutes input orderings under a reproducible seed.
Rotation search. Exhaustive (or sampled) rotation assignment search (rotation_search) enumerates all 2^k rotation assignments for k rotatable demand types, finding globally better rotation choices than greedy per-placement rotation.
Usable-drop consolidation. Set TwoDOptions.min_usable_side to filter out narrow leftover strips that are too small to reuse. The solver reports SheetLayout2D.largest_usable_drop_area (largest maximal free rectangle meeting the threshold on that sheet), SheetLayout2D.sum_sq_usable_drop_areas (sum of squares of all qualifying drops on that sheet), and aggregates across the solution as TwoDSolution.max_usable_drop_area (the MAX over all layouts, not the sum) and TwoDSolution.total_sum_sq_usable_drop_areas (saturating sum across layouts). Candidates that are equal on waste and cost are tiebroken in favour of larger / more consolidated drops; this tiebreaker sits AFTER total_waste_area and total_cost so waste and cost always dominate.
Integer-safe math. Dimensions are widened to u64 before area calculations; u32 * u32 on dimensions is forbidden by the workspace lint policy.

Cut plans

After solving, you can generate an ordered cut plan for any OneDSolution or TwoDSolution. The cut planner is a pure post-processor — it reads a finished layout and emits a per-bar or per-sheet sequence of CutSteps optimized for a chosen shop cost model. The solver is not re-run.

Entry points:

bin_packing::one_d::cut_plan::plan_cuts(&solution, &options) -> Result<CutPlanSolution1D, CutPlanError>
bin_packing::two_d::cut_plan::plan_cuts(&solution, &options) -> Result<CutPlanSolution2D, CutPlanError>

Presets (1D):

Preset	`cut_cost`	`fence_reset_cost`
`ChopSaw`	1.0	0.3

Presets (2D):

Preset	`cut_cost`	`rotate_cost`	`fence_reset_cost`	`tool_up_down_cost`	`travel_cost`
`TableSaw`	1.0	2.0	0.5	—	—
`PanelSaw`	1.0	5.0	0.3	—	—
`CncRouter`	1.0	—	—	0.2	0.01

Any cost field on the options struct overrides the preset default. Pass ..CutPlanOptions2D::default() to accept all preset defaults.

Output:

CutPlanSolution1D — contains bar_plans: Vec<BarCutPlan1D> and a solution-level total_cost. Each BarCutPlan1D carries:
- steps: Vec<CutStep1D> — ordered Cut and FenceReset steps.
- total_cost, num_cuts, num_fence_resets.
CutPlanSolution2D — contains sheet_plans: Vec<SheetCutPlan2D> and a solution-level total_cost. Each SheetCutPlan2D carries:
- steps: Vec<CutStep2D> — ordered Cut, LineCut, Rotate, FenceReset, ToolUp, ToolDown, and Travel steps.
- total_cost, num_cuts, num_rotations, num_fence_resets, num_tool_ups, travel_distance.

Total cost is the linear sum: num_cuts * cut_cost + num_rotations * rotate_cost + num_fence_resets * fence_reset_cost + num_tool_ups * tool_up_down_cost + travel_distance * travel_cost.

Errors (CutPlanError, #[non_exhaustive]):

NonGuillotineNotCuttable { sheet_name } — the layout cannot be expressed as a sequence of full guillotine cuts, and the TableSaw or PanelSaw preset was requested. Switch to CncRouter or re-solve with guillotine_required = true.
InvalidOptions(String) — a cost field is negative, NaN, or infinite.

Quick example (Rust):

use bin_packing::two_d::{
    RectDemand2D, Sheet2D, TwoDAlgorithm, TwoDOptions, TwoDProblem, solve_2d,
    cut_plan::{CutPlanOptions2D, CutPlanPreset2D, plan_cuts},
};

fn main() -> Result<(), Box<dyn std::error::Error>> {
    let problem = TwoDProblem {
        sheets: vec![Sheet2D {
            name: "plywood".into(),
            width: 96,
            height: 48,
            cost: 1.0,
            quantity: None,
            kerf: 2,
        }],
        demands: vec![
            RectDemand2D { name: "panel-a".into(), width: 24, height: 18, quantity: 4, can_rotate: true },
            RectDemand2D { name: "panel-b".into(), width: 12, height: 12, quantity: 6, can_rotate: true },
        ],
    };

    let solution = solve_2d(problem, TwoDOptions { algorithm: TwoDAlgorithm::Auto, ..Default::default() })?;

    let cut_plan = plan_cuts(
        &solution,
        &CutPlanOptions2D { preset: CutPlanPreset2D::TableSaw, ..Default::default() },
    )?;

    println!("total cut plan cost: {}", cut_plan.total_cost);
    for sheet_plan in &cut_plan.sheet_plans {
        println!("  {}: {} steps, cost {:.2}", sheet_plan.sheet_name, sheet_plan.steps.len(), sheet_plan.total_cost);
    }

    Ok(())
}

Cross-cutting

serde round-tripping. Every request, option, solution, and metrics type derives Serialize / Deserialize.
Reproducibility. All randomized strategies accept a seed; runs with identical seeds and inputs produce identical output.
Metrics. Each solution carries a metrics block (iterations, explored_states, etc.) plus free-form notes, so callers can surface diagnostics without re-running.
Benchmarks. Criterion benches live in crates/bin-packing/benches/solver_benches.rs.
Fuzzing. cargo fuzz run solver_inputs exercises the 1D, 2D, and 3D solvers against randomized inputs.

Algorithms

Selected via OneDOptions.algorithm, TwoDOptions.algorithm, or ThreeDOptions.algorithm. All names below are the exact snake_case strings accepted by serde and the Node / WebAssembly bindings.

3D (`ThreeDAlgorithm`)

Extreme Points family — maintains a set of extreme points (EPs) and places each item at the EP that scores best under the chosen criterion:

Name	Description
`extreme_points`	Volume-fit residual scoring (default EP variant).
`extreme_points_residual_space`	Crainic-Perboli-Tadei "RS" — scores by residual space remaining after placement.
`extreme_points_free_volume`	CPT "FV" — scores by free volume in the remaining space.
`extreme_points_bottom_left_back`	Bottom-left-back tiebreaking (place as close to the origin as possible).
`extreme_points_contact_point`	Score by surface contact with already-placed items or bin walls.
`extreme_points_euclidean`	CPT "EU" — scores by Euclidean distance of the EP from the bin origin.

Guillotine 3D beam search — recursive three-slab partition with configurable split and ranking rules:

Name	Description
`guillotine_3d`	Beam search with best-volume-fit ranking.
`guillotine_3d_best_short_side_fit`	Ranked by the shortest leftover edge after placement.
`guillotine_3d_best_long_side_fit`	Ranked by the longest leftover edge after placement.
`guillotine_3d_shorter_leftover_axis`	Split along the axis that leaves the shorter leftover slab.
`guillotine_3d_longer_leftover_axis`	Split along the axis that leaves the longer leftover slab.
`guillotine_3d_min_volume_split`	Split to minimise the volume of the new sub-cuboid.
`guillotine_3d_max_volume_split`	Split to maximise the volume of the new sub-cuboid.

Layer building — packs items into horizontal layers; each layer uses an independent 2D inner backend:

Name	Description
`layer_building`	Auto inner-2D backend (picks best of MaxRects, Skyline, Guillotine).
`layer_building_max_rects`	MaxRects inner backend.
`layer_building_skyline`	Skyline inner backend.
`layer_building_guillotine`	Guillotine inner backend.
`layer_building_shelf`	Best-fit-decreasing-height shelf inner backend.

Geometry-based heuristics:

Name	Description
`wall_building`	Bischoff & Marriott 1990 vertical wall-building: builds planar walls of items from floor to ceiling.
`column_building`	Vertical stack / column building with 2D footprint packing for column placement.
`deepest_bottom_left`	Deepest-Bottom-Left (Karabulut & İnceoğlu): place each item at the deepest, then bottom-most, then leftmost feasible position.
`deepest_bottom_left_fill`	Deepest-Bottom-Left-Fill: adds a fill pass to resolve deadlocks in DBL.
`first_fit_decreasing_volume`	Sort items by volume descending; assign each to the first bin with space.
`best_fit_decreasing_volume`	Sort items by volume descending; assign each to the bin with the least remaining volume that still fits.

Meta-strategies:

Name	Description
`multi_start`	Randomized EP meta-strategy. Runs `multistart_runs` restarts with shuffled item orderings under `seed`.
`grasp`	Greedy Randomized Adaptive Search: RCL-based randomized construction (top-30% by volume) followed by local search improvement.
`local_search`	Standalone local search seeded from FFD volume. Explores move/rotate/swap neighbourhood with bin-elimination repair.
`branch_and_bound`	Restricted Martello-Pisinger-Vigo exact backend. Computes L0/L1/L2 lower bounds; returns `Unsupported` for multi-bin-type, capped, or rotation-constrained inputs.
`auto` (default)	Tiered sweep: tier-1 runs ExtremePoints (3 variants), Guillotine3D, LayerBuilding, and FFD; tier-2 (when `multistart_runs > 0`) adds MultiStart and LocalSearch. Returns the best result.

Solution ranking for 3D is lexicographic on (unplaced, bin_count, total_waste_volume, total_cost, !exact).

1D (`OneDAlgorithm`)

Name	Description
`auto` (default)	Runs FFD, BFD, and local search, then optionally escalates to column generation when the instance is small enough (`auto_exact_max_types`, `auto_exact_max_quantity`, single uncapped stock). Returns the best candidate.
`first_fit_decreasing`	Classic FFD: sort cuts by length descending, place each into the first open bin that fits, open a new bin otherwise. O(n²) deterministic.
`best_fit_decreasing`	BFD: place each sorted cut into the open bin with the tightest fit. Typically uses fewer bins than FFD on mixed sizes.
`local_search`	Multistart local search seeded from FFD/BFD, with bin-elimination repair. `multistart_runs` restarts × `improvement_rounds` swap/move rounds, driven by `seed`.
`column_generation`	Exact backend: generates cutting patterns via price-and-solve, refines with pattern search, and enumerates up to `exact_pattern_limit` patterns per iteration for `column_generation_rounds` rounds. Reports an LP lower bound and sets `exact = true` when the bound is matched.

2D (`TwoDAlgorithm`)

MaxRects family — maintains an explicit set of free rectangles, scoring each candidate placement under a different criterion and then splitting / merging free rectangles:

Name	Description
`max_rects`	Best-area-fit MaxRects (the classic variant).
`max_rects_best_short_side_fit`	Prefer placements that minimize the shorter leftover edge.
`max_rects_best_long_side_fit`	Prefer placements that minimize the longer leftover edge.
`max_rects_bottom_left`	Bottom-left-first tiebreaking.
`max_rects_contact_point`	Score by perimeter contact with already-placed items or the sheet boundary.

Skyline family — maintains a monotone skyline along one axis:

Name	Description
`skyline`	Place each item at the lowest feasible skyline segment.
`skyline_min_waste`	Skyline construction with waste-minimizing candidate ranking, which keeps sub-skyline gaps smaller.

Guillotine beam search — recursive two-stage cuts with a beam-width search front (beam_width) and configurable split / ranking rules:

Name	Description
`guillotine`	Beam search with default (best-area-fit) ranking and default split.
`guillotine_best_short_side_fit`	Beam search ranked by shorter leftover edge.
`guillotine_best_long_side_fit`	Beam search ranked by longer leftover edge.
`guillotine_shorter_leftover_axis`	Split along the axis that leaves the shorter leftover strip.
`guillotine_longer_leftover_axis`	Split along the axis that leaves the longer leftover strip.
`guillotine_min_area_split`	Split to minimize the area of the new sub-rectangle.
`guillotine_max_area_split`	Split to maximize the area of the new sub-rectangle.

Shelf heuristics — simple fast baselines that stack items into horizontal "shelves" sized by the tallest item on each shelf:

Name	Description
`next_fit_decreasing_height`	NFDH: open a new shelf as soon as the current one overflows.
`first_fit_decreasing_height`	FFDH: place each item on the first shelf that fits.
`best_fit_decreasing_height`	BFDH: place each item on the tightest-fitting shelf.

Meta-strategies:

Name	Description
`multi_start`	Randomized MaxRects meta-strategy. Runs `multistart_runs` restarts with permuted item orderings under `seed`.
`rotation_search`	Exhaustive (or sampled) rotation assignment search: enumerates all 2^k rotation assignments for k rotatable demand types (or samples `multistart_runs` random assignments when k exceeds `auto_rotation_search_max_types`). Each assignment fixes rotations and packs via MaxRects best-area-fit.
`auto` (default)	Runs MaxRects (best-area, BSSF, BLSF, contact), Skyline and Skyline-min-waste, BFDH, Guillotine BSSF and shorter-leftover-axis, Multistart, and RotationSearch, then returns the best candidate. When `guillotine_required` is set, only the guillotine variants run.

Solution ranking for 2D is lexicographic on (unplaced, sheet_count, total_waste_area, total_cost, max_usable_drop_area↑, total_sum_sq_usable_drop_areas↑). The two consolidation keys (↑ = prefer larger) only reorder candidates that are already equal on every primary key; waste and cost always win. When guillotine_required is set, auto narrows its candidate set to the guillotine variants — the guillotine constraint is enforced by candidate selection, not by a ranking tie-break, so every candidate auto ranks is already guillotine-compatible.

Rust usage

Add the crate to your Cargo.toml:

[dependencies]
bin-packing = "0.3"

The dimension modules expose three entry points:

one_d::solve_1d(problem, options) -> Result<OneDSolution>
two_d::solve_2d(problem, options) -> Result<TwoDSolution>
three_d::solve_3d(problem, options) -> Result<ThreeDSolution>

All problem and solution types implement serde::Serialize / serde::Deserialize, so the same models are usable from Rust code or wire-format APIs. The crate root re-exports BinPackingError and Result; everything else comes from the one_d, two_d, and three_d modules.

1D cutting stock

use bin_packing::one_d::{
    CutDemand1D, OneDAlgorithm, OneDOptions, OneDProblem, Stock1D, solve_1d,
};

fn main() -> bin_packing::Result<()> {
    let problem = OneDProblem {
        stock: vec![Stock1D {
            name: "96in bar".into(),
            length: 96,
            kerf: 1,
            trim: 0,
            cost: 1.0,
            available: None,
        }],
        demands: vec![
            CutDemand1D { name: "rail".into(), length: 45, quantity: 2 },
            CutDemand1D { name: "brace".into(), length: 30, quantity: 2 },
        ],
    };

    let solution = solve_1d(
        problem,
        OneDOptions {
            algorithm: OneDAlgorithm::Auto,
            ..Default::default()
        },
    )?;

    println!("algorithm: {}", solution.algorithm);
    println!("stock used: {}", solution.stock_count);
    println!("waste: {}", solution.total_waste);
    println!("exact: {}", solution.exact);
    if let Some(bound) = solution.lower_bound {
        println!("lower bound: {bound}");
    }

    for layout in &solution.layouts {
        println!(
            "{}: used {} / {}",
            layout.stock_name, layout.used_length, layout.stock_length
        );
    }

    for requirement in &solution.stock_requirements {
        println!(
            "{}: used {}, required {}, additional {}",
            requirement.stock_name,
            requirement.used_quantity,
            requirement.required_quantity,
            requirement.additional_quantity_needed,
        );
    }

    Ok(())
}

Stock1D fields:

length: raw stock length before trim is removed.
kerf: material lost to the saw between adjacent cuts.
trim: unusable material removed from the stock length before packing.
cost: per-unit cost of consuming one piece of this stock type.
available: optional inventory cap (number of pieces of this type that may be used).

OneDOptions fields:

algorithm: auto (default), first_fit_decreasing, best_fit_decreasing, local_search, or column_generation.
multistart_runs: number of restarts for local search (default 16).
improvement_rounds: improvement passes per local-search start (default 24).
column_generation_rounds: outer rounds for the exact backend (default 32).
exact_pattern_limit: maximum patterns enumerated per round in the exact backend (default 25_000).
auto_exact_max_types: maximum distinct demand types for Auto mode to attempt the exact backend (default 14).
auto_exact_max_quantity: maximum total demand quantity for Auto mode to attempt the exact backend (default 96).
seed: optional RNG seed for reproducible randomized algorithms.

OneDSolution fields of interest:

algorithm / exact / lower_bound
stock_count, total_waste, total_cost
layouts: per-piece StockLayout1D entries (stock name, used/remaining length, waste, cost, and cut list), sorted by utilization descending.
stock_requirements: per-stock procurement summary including any shortage against the declared available inventory. When inventory caps are present this is computed from a relaxed-inventory Auto re-solve.
unplaced: cuts the solver could not place (normally empty unless inventory capped the solution).
metrics: iterations, generated_patterns, enumerated_patterns, explored_states, and diagnostic notes.

2D rectangular packing

use bin_packing::two_d::{
    RectDemand2D, Sheet2D, TwoDAlgorithm, TwoDOptions, TwoDProblem, solve_2d,
};

fn main() -> bin_packing::Result<()> {
    let problem = TwoDProblem {
        sheets: vec![Sheet2D {
            name: "plywood".into(),
            width: 96,
            height: 48,
            cost: 1.0,
            quantity: None,
            kerf: 2,
        }],
        demands: vec![
            RectDemand2D {
                name: "panel-a".into(),
                width: 24,
                height: 18,
                quantity: 4,
                can_rotate: true,
            },
            RectDemand2D {
                name: "panel-b".into(),
                width: 12,
                height: 12,
                quantity: 6,
                can_rotate: true,
            },
        ],
    };

    let solution = solve_2d(
        problem,
        TwoDOptions {
            algorithm: TwoDAlgorithm::Auto,
            seed: Some(42),
            ..Default::default()
        },
    )?;

    println!("algorithm: {}", solution.algorithm);
    println!("sheets used: {}", solution.sheet_count);
    println!("waste area: {}", solution.total_waste_area);
    println!("guillotine: {}", solution.guillotine);

    for layout in &solution.layouts {
        println!(
            "{}: {} placements, {} waste area",
            layout.sheet_name,
            layout.placements.len(),
            layout.waste_area
        );
        for placement in &layout.placements {
            println!(
                "  {} @ ({}, {}) {}x{}{}",
                placement.name,
                placement.x,
                placement.y,
                placement.width,
                placement.height,
                if placement.rotated { " rotated" } else { "" },
            );
        }
    }

    Ok(())
}

Sheet2D fields:

width, height: sheet dimensions (positive, up to 1 << 30).
cost: per-unit cost of consuming one sheet of this type.
quantity: optional cap on the number of sheets of this type that may be used.
kerf: optional saw-blade kerf width (default 0). The solver enforces this gap between every pair of adjacent placements on the sheet; the gap between a placement and the sheet edge is free (factory edge rule).
edge_kerf_relief: when true, the trailing placement on the sheet may extend up to one kerf past the sheet's right and bottom edges, modeling a cut that exits the stock (default false). Individual parts must still fit within the sheet's declared dimensions.

RectDemand2D fields:

width, height: rectangle dimensions (positive, up to 1 << 30).
quantity: number of identical rectangles required.
can_rotate: whether the solver may rotate this rectangle 90°.

TwoDOptions fields:

algorithm: see the 2D algorithm table above; defaults to auto.
multistart_runs: number of restarts for the multistart meta-strategy.
beam_width: beam width for the guillotine beam search backend.
guillotine_required: when true, forces guillotine-compatible layouts and restricts auto to guillotine variants.
min_usable_side: minimum side length (in the same units as sheet dimensions) for a leftover drop to count as usable (default 0 — all drops count). Raise this to ignore narrow strips that are too small to reuse; the consolidation tiebreakers then favour solutions that leave fewer but larger reusable offcuts.
auto_rotation_search_max_types: maximum number of rotatable demand types for which rotation search uses exhaustive enumeration (default 16). When the number of rotatable types exceeds this threshold, rotation search switches to sampling multistart_runs random assignments.
seed: optional RNG seed for reproducible randomized algorithms.

TwoDSolution fields of interest:

algorithm, guillotine
sheet_count, total_waste_area, total_kerf_area, total_cost
max_usable_drop_area: the largest single usable drop area across all layouts (MAX over layouts, not a sum). A drop qualifies when both its sides are at least min_usable_side.
total_sum_sq_usable_drop_areas: saturating sum of sum_sq_usable_drop_areas across all layouts. Higher values indicate better drop consolidation (fewer but larger reusable offcuts).
layouts: per-sheet SheetLayout2D entries (sheet name, dimensions, placements, used area, waste area, kerf_area — the portion of waste_area attributable to kerf gaps — largest_usable_drop_area, and sum_sq_usable_drop_areas).
placements: each Placement2D carries x, y, width, height, and rotated (whether the rectangle was rotated from its declared orientation).
unplaced: demands the solver could not place.
metrics: iterations, explored_states, and diagnostic notes.

3D box packing

use bin_packing::three_d::{
    Bin3D, BoxDemand3D, RotationMask3D, ThreeDAlgorithm, ThreeDOptions,
    ThreeDProblem, solve_3d,
};

fn main() -> bin_packing::Result<()> {
    let problem = ThreeDProblem {
        bins: vec![Bin3D {
            name: "pallet".into(),
            width: 120,
            height: 100,
            depth: 80,
            cost: 1.0,
            quantity: None,
        }],
        demands: vec![
            BoxDemand3D {
                name: "carton-a".into(),
                width: 30,
                height: 25,
                depth: 20,
                quantity: 6,
                allowed_rotations: RotationMask3D::ALL,
            },
            BoxDemand3D {
                name: "carton-b".into(),
                width: 20,
                height: 15,
                depth: 10,
                quantity: 8,
                allowed_rotations: RotationMask3D::UPRIGHT,
            },
        ],
    };

    let solution = solve_3d(
        problem,
        ThreeDOptions {
            algorithm: ThreeDAlgorithm::Auto,
            seed: Some(42),
            ..Default::default()
        },
    )?;

    println!("algorithm: {}", solution.algorithm);
    println!("bins used: {}", solution.bin_count);
    println!("waste volume: {}", solution.total_waste_volume);

    for layout in &solution.layouts {
        println!(
            "{}: {} placements, {} waste volume",
            layout.bin_name,
            layout.placements.len(),
            layout.waste_volume
        );
        for placement in &layout.placements {
            println!(
                "  {} @ ({}, {}, {}) {}x{}x{} rotation={:?}",
                placement.name,
                placement.x, placement.y, placement.z,
                placement.width, placement.height, placement.depth,
                placement.rotation,
            );
        }
    }

    Ok(())
}

Bin3D fields:

width, height, depth: bin dimensions (positive, up to 1 << 15).
cost: per-unit cost of consuming one bin of this type.
quantity: optional cap on the number of bins of this type that may be used.

BoxDemand3D fields:

width, height, depth: declared box dimensions (positive, up to 1 << 15).
quantity: number of identical boxes required.
allowed_rotations: bitmask of the six axis-permutation orientations permitted for this box. Use RotationMask3D::ALL (all six), RotationMask3D::UPRIGHT (only Xyz and Zyx, keeping the y-axis vertical), or construct a custom mask from the per-rotation constants (RotationMask3D::XYZ, XZY, YXZ, YZX, ZXY, ZYX).

ThreeDOptions fields:

algorithm: see the 3D algorithm table above; defaults to auto.
multistart_runs: number of restarts for randomized meta-strategies.
improvement_rounds: improvement passes per local-search or GRASP start.
beam_width: beam width for the Guillotine 3D beam search backend.
seed: optional RNG seed for reproducible randomized algorithms.
auto_exact_max_types / auto_exact_max_quantity: thresholds controlling when Auto mode may escalate to the exact branch-and-bound backend.
branch_and_bound_node_limit: maximum nodes the exact backend may expand.

ThreeDSolution fields of interest:

algorithm, exact, lower_bound, guillotine
bin_count, total_waste_volume, total_cost
layouts: per-bin BinLayout3D entries (bin name, dimensions, placements, used_volume, waste_volume).
placements: each Placement3D carries x, y, z, width, height, depth, and rotation (the Rotation3D variant applied).
bin_requirements: per-bin procurement summary (populated when at least one Bin3D.quantity cap is set).
unplaced: boxes the solver could not place.
metrics: iterations, explored_states, extreme_points_generated, branch_and_bound_nodes, and diagnostic notes.

Errors

BinPackingError is #[non_exhaustive]. Match it with a wildcard arm.

InvalidInput(String) — problem failed boundary validation (empty stock/sheet list, zero dimension, non-finite cost, trim ≥ length, etc.).
Infeasible1D { item, length } — a 1D demand does not fit any declared stock.
Infeasible2D { item, width, height } — a 2D demand does not fit any declared sheet, even with rotation.
Infeasible3D { item, width, height, depth } — a 3D demand does not fit any declared bin in any allowed rotation.
Unsupported(String) — the exact backend encountered a configuration it does not currently handle (for example, multi-stock input or capped inventory for column generation), or an internal invariant violation was caught by a defensive check at runtime.

Node.js usage

Build the binding from bindings/node:

pnpm install
pnpm run build

Then call the wrapper with plain JavaScript objects. Field names match the Rust serde representation (snake_case):

const binPacking = require('@0xdoublesharp/bin-packing');

const cutList = binPacking.solve1d(
  {
    stock: [{ name: 'bar', length: 100, kerf: 1, available: 5 }],
    demands: [
      { name: 'A', length: 45, quantity: 2 },
      { name: 'B', length: 30, quantity: 2 }
    ]
  },
  { algorithm: 'auto', seed: 7 }
);

console.log(cutList.stock_count);
console.log(cutList.stock_requirements);
console.log(cutList.unplaced);

const layout = binPacking.solve2d(
  {
    sheets: [{ name: 'plywood', width: 96, height: 48, kerf: 2 }],
    demands: [
      { name: 'panel', width: 24, height: 18, quantity: 4, can_rotate: true }
    ]
  },
  { algorithm: 'auto', guillotine_required: true, beam_width: 12 }
);

console.log(layout.sheet_count, layout.total_waste_area, layout.guillotine);

const packing = binPacking.solve3d(
  {
    bins: [{ name: 'pallet', width: 120, height: 100, depth: 80 }],
    demands: [
      { name: 'carton-a', width: 30, height: 25, depth: 20, quantity: 6 },
      { name: 'carton-b', width: 20, height: 15, depth: 10, quantity: 8 }
    ]
  },
  { algorithm: 'auto', seed: 42 }
);

console.log(packing.bin_count, packing.total_waste_volume);

TypeScript type definitions ship alongside the JavaScript wrapper in bindings/node/wrapper.d.ts. Both camelCase (solve1D / solve2D / solve3D) and lowercase (solve1d / solve2d / solve3d) aliases are exported, plus a version() helper.

Browser / WASM usage

For browsers, Deno, Bun, and Cloudflare Workers (or anywhere else a native Node addon is inconvenient), the WebAssembly binding at bindings/wasm publishes to npm as @0xdoublesharp/bin-packing-wasm. It ships combined and dimension-specific targets through a single package:

pnpm add @0xdoublesharp/bin-packing-wasm

// Bundlers (Vite, webpack, esbuild, Next.js, Rollup, Parcel)
import { solve1d, solve2d } from '@0xdoublesharp/bin-packing-wasm';

// Smaller dimension-specific browser bundles
import { solve1d as solveCutList } from '@0xdoublesharp/bin-packing-wasm/one-d';
import { solve2d as solveSheets } from '@0xdoublesharp/bin-packing-wasm/two-d';
import { solve3d as packBoxes } from '@0xdoublesharp/bin-packing-wasm/three-d';

// Raw ES modules / Deno — explicit init required
import init, { solve2d } from '@0xdoublesharp/bin-packing-wasm/web';
await init();

// Node.js / Bun — synchronous load, no init
import { solve1d } from '@0xdoublesharp/bin-packing-wasm/nodejs';

The API is identical to the Node binding: plain JS objects go in, plain JS objects come out, and errors throw native JavaScript exceptions with the original BinPackingError message. Full TypeScript types are included. The combined output is ~550 KB of wasm-opt -Oz-optimized WebAssembly (1D+2D+3D); the dimension-specific browser outputs are currently ~200 KB for 1D, ~230 KB for 2D, and ~300 KB for 3D. These are approximate — run the build locally for current figures.

Build it locally:

cd bindings/wasm
rustup target add wasm32-unknown-unknown
cargo install wasm-pack
pnpm run build  # builds combined and dimension-specific targets into dist/
pnpm test       # runs the Node smoke test against dist/nodejs

See bindings/wasm/README.md for the full API reference and per-target usage examples.

Repository layout

crates/bin-packing/          # core solver crate
  src/one_d/                 #   1D model, heuristics, and exact backend
  src/two_d/                 #   2D model, MaxRects, Skyline, Guillotine, Shelf, RotationSearch
  src/three_d/               #   3D model, 29-algorithm catalog
  benches/solver_benches.rs  #   Criterion benchmarks (1D + 2D + 3D)
  tests/solver_regressions.rs
bindings/node/               # napi-rs Node.js bindings (@0xdoublesharp/bin-packing)
bindings/wasm/               # wasm-bindgen WebAssembly bindings (@0xdoublesharp/bin-packing-wasm)
fuzz/fuzz_targets/           # cargo-fuzz / libFuzzer targets (1D + 2D + 3D)
AGENTS.md                    # contributor rules

Verification

Core Rust checks (matches CI gate described in AGENTS.md):

cargo fmt --check
cargo clippy --workspace --all-targets --all-features -- -D warnings
cargo test --workspace --all-targets

Criterion benchmarks:

cargo bench -p bin-packing --bench solver_benches -- --sample-size 10

Node binding smoke test:

cd bindings/node
pnpm test

WebAssembly binding build and smoke test:

cd bindings/wasm
pnpm run build
pnpm test

Fuzz target build and execution:

cargo check --manifest-path fuzz/Cargo.toml
cargo fuzz run solver_inputs

Name		Name	Last commit message	Last commit date
Latest commit History 9 Commits
.github/workflows		.github/workflows
bindings		bindings
crates/bin-packing		crates/bin-packing
docs		docs
fuzz		fuzz
.gitignore		.gitignore
AGENTS.md		AGENTS.md
Cargo.lock		Cargo.lock
Cargo.toml		Cargo.toml
README.md		README.md
rust-toolchain.toml		rust-toolchain.toml
rustfmt.toml		rustfmt.toml

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Repository files navigation

Bin Packing

Features

1D cutting stock

3D box packing

2D rectangular packing

Cut plans

Cross-cutting

Algorithms

3D (`ThreeDAlgorithm`)

1D (`OneDAlgorithm`)

2D (`TwoDAlgorithm`)

Rust usage

1D cutting stock

2D rectangular packing

3D box packing

Errors

Node.js usage

Browser / WASM usage

Repository layout

Verification

About

Uh oh!

Releases 4

Packages

Uh oh!

Contributors

Uh oh!

Languages

Folders and files

Latest commit

History

Repository files navigation

Bin Packing

Features

1D cutting stock

3D box packing

2D rectangular packing

Cut plans

Cross-cutting

Algorithms

3D (ThreeDAlgorithm)

1D (OneDAlgorithm)

2D (TwoDAlgorithm)

Rust usage

1D cutting stock

2D rectangular packing

3D box packing

Errors

Node.js usage

Browser / WASM usage

Repository layout

Verification

About

Resources

Uh oh!

Stars

Watchers

Forks

Releases 4

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

3D (`ThreeDAlgorithm`)

1D (`OneDAlgorithm`)

2D (`TwoDAlgorithm`)

Packages
