Custom FPGA-Accelerated Tiny-YOLO on Xilinx ZCU102

End-to-end project: custom OS image → model training → HLS accelerator → live inference on FPGA. Final result: 2.7 FPS on ZCU102 — 11.6× faster than the V1 baseline.

---

Demo

---

Project Overview

This project builds a complete hardware-accelerated object detection pipeline from scratch on the Xilinx ZCU102 (Zynq UltraScale+). The Tiny-YOLO v2 model runs with all 10 convolutional layers offloaded to the FPGA programmable logic via a custom HLS IP, while the ARM PS handles preprocessing, weight loading, and YOLO post-processing.

┌─────────────────────────────────────────────────────────────────────────┐
│                              ZCU102 SoC                                 │
│                                                                         │
│   PS (ARM Cortex-A53)                     PL (FPGA Fabric)              │
│   ┌──────────────────────┐                ┌────────────────────────┐    │
│   │ • Image capture      │  AXI4 256-bit  │  Fetch ─▶ Execute      │    │
│   │ • Weight loading     │◀──────────────▶│               ─▶ Write │    │
│   │ • BN fusion (Q8.8)   │  AXI-Lite      │                        │    │
│   │ • YOLO decode + NMS  │───────────────▶│  256-MAC array         │    │
│   │ • Display output     │                │  Fused BN + LeakyReLU  │    │
│   └──────────────────────┘                └────────────────────────┘    │
└─────────────────────────────────────────────────────────────────────────┘

---

Repository Structure

├── OS/                          # Step 0 — Custom PYNQ image build
│   └── README.md
├── Training/                    # Step 1 — Model training (RTX 4090)
│   ├── ObjectDetection.ipynb
│   └── README.md
├── Models/                      # Trained weights
│   ├── tiny_yolo_best.pth
│   └── tiny_yolo_best_iou.pth
├── PS/                          # Step 2 — CPU inference (PS-side testing)
│   ├── run_yolo_opencv.py
│   └── README.md
├── HLS/                         # Step 3 — HLS accelerator design
│   ├── conv_engine.h
│   ├── conv_engine.cpp
│   ├── conv_engine_tb.cpp
│   ├── run_hls.tcl
│   └── Vivado/
│       └── ConvBlock/           # Vivado block design project
├── PL/                          # Step 4 — PYNQ deployment & inference
│   ├── tinyyolo_pynq.ipynb
│   └── README.md
└── .gitignore

---

End-to-End Flow

Step 0 — Build the OS

OS/README.md

Built a custom PYNQ 3.1.2 SD card image for the ZCU102 using Vivado/PetaLinux 2024.1 and Docker.

Key lesson: use the correct toolchain version and build from source — do not use cached prebuilt rootfs.

make BOARDDIR=/workspace/sdbuild/boards BOARD=ZCU102
# ~2 hours → ZCU102-3.1.2.img

---

Step 1 — Train the Model

Training/README.md

Trained Tiny-YOLO v2 on COCO 2017 (80 classes) from scratch using PyTorch on an RTX 4090 with full CUDA optimizations.

Setting	Value
Architecture	Tiny-YOLO v2 (9× ConvBlock + detection)
Dataset	COCO 2017 (118K train / 5K val)
Loss	CIoU + label smoothing
Precision	AMP (FP16) with TF32 tensor cores
Output	tiny_yolo_best.pth, tiny_yolo_best_iou.pth

---

Step 2 — Test on PS (CPU Inference)

PS/README.md

Quick sanity-check script to verify model detection quality on the ARM PS before committing to hardware deployment. Uses PyTorch + OpenCV, no FPGA required.

python PS/run_yolo_opencv.py --weights Models/tiny_yolo_best.pth --image photo.jpg

---

Step 3 — HLS Accelerator Design

HLS/

Custom three-stage dataflow HLS IP core (conv_engine) that executes all 10 Tiny-YOLO layers on the FPGA fabric.

Architecture:

DDR ──▶ Fetch_Layer ──▶ Execute_Layer ──▶ Write_Layer ──▶ DDR
          (DMA)          (256-MAC array)     (MaxPool)

Data format: ap_fixed<16,8> (Q8.8 fixed point)
Memory bus: 256-bit AXI (ap_uint<256> = 16 values/beat)
MAC array: 16 OC × 16 IC = 256 MACs/cycle at II=1

Three major design revisions:

Version	Clock	FPS	Status
V1	143 MHz	0.31	Baseline — naive DRAM access, 1.8% compute utilization
V2	250 MHz	—	FAILED — timing violation (−2.05 ns), 61B cycle latency
V3	167 MHz	2.7	Deployed — 4/4 burst ports, 29.6% compute utilization

Key V3 breakthroughs:

• IC-outer loop ordering — input read once per IC tile, reused across all OC tiles (up to 64× fewer DRAM reads)
• DMA staging buffers — dma_line, dma_wt, dma_out guarantee burst inference on all 4 AXI ports
• Phase-separated writes — READ → PACK → BURST WRITE, no interleaved R/W

Build:

cd HLS/
vitis-run --mode hls --tcl run_hls.tcl

---

Step 4 — Vivado Block Design

HLS/Vivado/ConvBlock/

Vivado block design connecting the HLS IP to the Zynq PS via 4 AXI master ports (gmem0–gmem3) and an AXI-Lite control interface.

Component	Role
conv_engine_1	HLS IP core
axi_smc_gmem0–3	SmartConnect for 4 DDR channels
zynq_ultra_ps_e_0	PS + DDR4 controller

---

Step 5 — Deploy and Run on PYNQ

PL/README.md

Full inference pipeline notebook (tinyyolo_pynq.ipynb) running on the ZCU102 under PYNQ:

from pynq import Overlay
ol = Overlay('tinyyolo_zcu102_v3.3.bit')
conv_ip = ol.conv_engine_1
# → loads weights, runs all 10 layers on FPGA, decodes YOLO output, draws boxes

---

Results

Performance (V3, ZCU102 @ 167 MHz)

Layer	Time (ms)	Output
conv1	57.31	16×208×208
conv2	37.70	32×104×104
conv3	24.30	64×52×52
conv4	19.82	128×26×26
conv5	15.99	256×13×13
conv6	17.17	512×13×13
conv7	57.58	1024×13×13
conv8	16.69	256×13×13
conv9	17.08	512×13×13
det	13.40	425×13×13
Total HW	277 ms	—
Wall time	~370 ms	~2.7 FPS

Resource Utilization (Post-Route)

Resource	Used	Available	Util%
LUT	105,148	274,080	38.4%
FF	145,010	548,160	26.5%
BRAM	362	912	39.7%
DSP48E2	355	2,520	14.1%

Power: 6.98 W total (PL: ~3.48 W)

Version Comparison

Metric	V1	V3	Gain
HW time	3,207 ms	277 ms	11.6×
Compute utilization	1.8%	29.6%	16.4×
LUT utilization	74%	38%	halved
Burst ports active	0/4	4/4	full

---

Requirements

Component	Version
Board	Xilinx ZCU102 (xczu9eg-ffvb1156-2-e)
OS	Custom PYNQ 3.1.2 (see OS/)
HLS/Vivado	Vitis HLS 2024.1, Vivado 2024.1
Training	PyTorch, CUDA, RTX 4090
Runtime	Python 3, PYNQ 3.0+, OpenCV, NumPy

---

Roadmap

Current: 2.7 FPS → Target: 30 FPS

Optimization	Expected Gain	Complexity
Wider MAC (TILE_OC=32 → 512 MACs)	1.5–2×	Low
512-bit AXI bus	1.3×	Low
Clock to 200 MHz	1.2×	Medium
Multi-CU (2× conv_engine)	1.8×	Medium
Layer fusion (no inter-layer DDR)	1.3×	High
