What is Phantom-WG Modern?

Phantom-WG is a modular tool that lets you set up and manage a WireGuard VPN infrastructure on your own server. Beyond basic VPN management, it offers censorship-resistant connections, multi-layered encryption, and advanced privacy scenarios.

Phantom-WG Modern is the container-native implementation of this vision. All components run within Docker and are isolated from the host system:

• Userspace WireGuard — Container-scoped TUN device via Go FFI bridge. No kernel module required, does not touch the host's network namespace.
• nftables netlink FFI — Rust backend communicates directly with the kernel. No subprocess calls, firewall rules are managed programmatically.
• SQLite State Persistence — All state is stored in SQLite databases. A daemon restart after a crash is sufficient — kernel state is rebuilt from the DB.
• Dual-Stack IPv6 — Even without IPv6 on the host, an IPv6 subnet is assigned within the container and traffic is carried through the tunnel.
• Container Isolation — NET_ADMIN + NET_RAW is sufficient. WireGuard interfaces live within the container namespace. Configurations that weaken host security such as SYS_ADMIN, privileged, or host network mode are not used.

---

Topology

Three containers, managed via Docker Compose. Management traffic passes through TLS + JWT authentication, WireGuard traffic reaches the daemon directly.

flowchart
    A[Internet] -->|"HTTPS :443"| B[nginx]
    B --> C[auth-service]
    C <-->|"UDS"| D[daemon]
    A -->|"WireGuard :51820/udp"| D

Loading

Component	Role
nginx	TLS termination, React SPA (static compiled files), reverse proxy configuration
auth-service	Comprehensive authentication system, API proxy to daemon over UDS
daemon	Userspace WireGuard (Go FFI), nftables firewall (Rust FFI), client and tunnel management, databases

---

Key Features

Bridge Architecture

The daemon performs system-level operations through two native bridges. Python manages the business logic, bridges communicate directly with the kernel.

graph
    D["Daemon (Python)"] -->|"ctypes FFI"| WG["wireguard-go-bridge (Go)"]
    D -->|"ctypes FFI"| FW["firewall-bridge (Rust)"]
    WG --> TUN["TUN device"]
    FW --> NFT["nftables kernel"]

Loading

Bridge	Language	Responsibility
wireguard-go-bridge	Go	Userspace WireGuard, TUN device, IPC state persistence
firewall-bridge	Rust	nftables rule groups, policy routing, preset system

Multihop Exit Routing

You can define your exit tunnel to route traffic through an external WireGuard VPN server. IPv4 and IPv6 tunnels are supported simultaneously.

flowchart LR
    C[Client] -->|"WireGuard"| M["wg_main"] -->|"forward + masquerade"| E["wg_exit"] --> X[Exit Server]

Loading

IPv6 Dual-Stack

IPv6 support across all layers — firewall rules, policy routing, masquerade, and multihop presets operate with family: 10 (AF_INET6). IPv6 tunnel traffic can be carried from within the container even without an IPv6 address on the host.

Crash Recovery

When the service starts, kernel state (nftables rules, routing policies) is rebuilt from SQLite state databases. No data loss after an unexpected shutdown.

---

Auth-Service (Authentication and Secure Proxy Layer)

Access to the daemon is protected by an independent authentication service. Auth-service runs in a separate container from the daemon and proxies API requests over UDS.

Authentication

Feature	Detail
Session management	JWT (Ed25519 signed)
Multi-factor authentication	TOTP (RFC 6238), backup code access
Password storage	Argon2id hash
Brute-force protection	IP-based rate limiting (configurable sliding window and attempt-based configuration)
Audit log	All authentication and API proxy events are logged per user (login, logout, failed attempt, MFA)

RBAC (Role-Based Access Control)

Permission	Superadmin	Admin
Daemon management (client, multihop, firewall, backup)	✓	✓
Change own password	✓	✓
Configure own TOTP	✓	✓
Create / delete admin accounts	✓	—
Change any user's password	✓	—
Disable another user's TOTP	✓	—
View audit log	✓	—

Tip

The account created during initial setup has the superadmin role. If multiple people manage the server, admin accounts can be created for operational access — administrative privileges remain with the superadmin.

Both roles can manage the daemon at the same permission level — all operations executed through the daemon such as client creation, multihop, firewall, and backup are shared. The distinction is only on the auth-service side: superadmin has user management and audit authority, while admin has only operational access. Auth-service is an independent component — customizations do not affect the daemon structure. The daemon is unaware of this service's existence and only handles network operations. If you want to isolate different user groups, instead of authorization through auth-service, you can set up a multi-tenant structure running on the same host through configuration changes. This way, you can create independent instances by multiplying port and network configurations while ensuring isolation on both the network and user access sides. These operational configurations are for advanced users who want to adapt the existing structure to their own scenario.

---

Installation

Prerequisites: Docker Engine 20.10+, Docker Compose v2, bash.

curl -sSL get.phantom.tc | bash

Configuration

cd phantom-wg

# First-time setup
./tools/prod.sh setup

# Endpoint configuration
IPV4=$(curl -4 -sSL https://get.phantom.tc/ip)
IPV6=$(curl -6 -sSL https://get.phantom.tc/ip)
sed -i "s/^WIREGUARD_ENDPOINT_V4=.*/WIREGUARD_ENDPOINT_V4=${IPV4}/" .env.daemon
sed -i "s/^WIREGUARD_ENDPOINT_V6=.*/WIREGUARD_ENDPOINT_V6=${IPV6}/" .env.daemon

# Start
./tools/prod.sh up

Access:

• Dashboard: https://<server-ip>
• WireGuard: UDP port 51820
• Admin password: cat container-data/secrets/production/.admin_password

Tip

To access the dashboard while connected to the VPN, use the nginx container's Docker network address:

docker inspect phantom-nginx --format '{{range .NetworkSettings.Networks}}IPv4: {{.IPAddress}} | IPv6: {{.GlobalIPv6Address}}{{end}}'

Accessible via https://<IPv4> or https://[<IPv6>] through the tunnel. You can also remove the ports: "443:443" line from docker-compose.yml to make the dashboard accessible only through the VPN tunnel.

---

Environment Variables

Configuration is managed through env files created from templates during setup:

File	Service
.env.daemon	daemon
.env.auth-service	auth-service

See .example files for all available options.

---

Management

A convenient tool is available at ./tools/prod.sh for management.

Command	Description
setup	Full Setup
up	Start
down	Stop
restart [service]	Restart (All or Specific Service)
build	Build Images
rebuild	Build Images from Scratch (no-cache)
update	Update (git pull + restart)
update --skip-compose	Update (exclude docker-compose.yml)
logs [service]	Log Tracking (All or Specific Service)
status	Docker Compose Status
show-versions	Component Versions (Daemon, Vendor Packages)
shell [service]	Shell (default: daemon)
exec <svc> <cmd>	Execute Command
hard-reset	Delete All Data

Setup

The setup command creates all required components during first-time installation:

1. Creates .env.daemon and .env.auth-service files from .example templates.
2. Generates WireGuard server key pair. (Curve25519 — wg_private_key, wg_public_key)
3. Auth-Service bootstrap cycle:
   • Generates Ed25519 signing key pair. (auth_signing_key, auth_verify_key)
   • Creates auth database. (auth.db — users, sessions, TOTP, audit log)
   • Creates admin account. (32-character random password encrypted with Argon2id hash)
4. Generates self-signed TLS certificate for nginx. (tls_cert, tls_key)

All of these operations take place within the container — no additional dependencies or tools need to be installed on the host.

Tip

Secret keys are stored under container-data/secrets/production/. The admin password is written to .admin_password in the same directory — you can safely remove it after logging in.

Updating

./tools/prod.sh update                 # git pull + restart
./tools/prod.sh update --skip-compose  # Preserve compose file

Tip

If you have made configuration changes to docker-compose.yml and want to receive updates, use --skip-compose.

For package dependency changes that require container recompilation (Dockerfile, requirements.txt):

./tools/prod.sh rebuild
./tools/prod.sh up

Tip

Dockerfiles only provide the system dependencies needed for the stack to run. Code updates are received with the update command — rebuild is only required when these dependencies change (in updates requiring container recompilation).

---

Architecture

For detailed architecture documentation, visit www.phantom.tc/docs/architecture.

Resource	URL
Website	www.phantom.tc
Architecture	www.phantom.tc/docs/architecture
API Reference	www.phantom.tc/docs/api
Setup Guide	SETUP

---

Development

Active development takes place on the dev/daemon branch. The main branch contains production-ready releases only.

---

Phantom-WG Retro

If you are looking for advanced privacy features and a solution that runs solely on system services, Phantom-WG Retro may interest you.

MultiGhost - Maximum Privacy

Achieve the highest level of privacy and censorship resistance by using Ghost and Multihop modules together. Your connection is masked as HTTPS and routed through a double VPN layer.

Activation:

# 1. Enable Ghost Mode
phantom-api ghost enable domain="cdn.example.com"

# 2. Import external VPN
phantom-api multihop import_vpn_config config_path="/path/to/vpn.conf"

# 3. Enable Multihop
phantom-api multihop enable_multihop exit_name="vpn-exit"

Explore

	Resource	Link
🌐	Homepage	www.phantom.tc
📖	Documentation	retro-docs.phantom.tc
💻	Source Code	GitHub Repository
🍎	Mac Client	v1.0.0

---

Trademark Notice

WireGuard® is a registered trademark of Jason A. Donenfeld.

This project is not affiliated, associated, authorized, endorsed by, or in any way officially connected with Jason A. Donenfeld, ZX2C4 or Edge Security.

---

License

Copyright (c) 2025 Riza Emre ARAS

Licensed under AGPL-3.0. See THIRD_PARTY_LICENSES for dependency licenses.
